base64이미지 사용에 관련한 설정을 합니다.

설정

Key설명
editor.upload.image.base64

이미지 업로드 시 base64를 사용할 것인지를 설정합니다. (기본값 false)

true로 설정되면 이미지 삽입 시 서버로 이미지를 업로드 하지 않고 본문에 base64로 인코딩하여 표시합니다.

editor.image.base64.maxSize

릴리즈 3.0.2404 이상 릴리즈 2.18.2404 이상 base64로 삽입되는 이미지의 최대 파일사이즈를 설정합니다. (단위 byte, 기본값은 제한없음)

이 사이즈는 브라우저(Client)에서 설정하는 값으로 실제 파일 사이즈와 일부 다를 수 있습니다.


설정 예시

synapeditor.config.js
{
	'editor.upload.image.base64': true,
	'editor.image.base64.maxSize': 102400, // 100KB
}

editor.upload.image.base64 결과 예시

<div class="se-contents" style="font-family: Arial, Helvetica, sans-serif; font-size: 11pt; line-height: 1.2; padding: 25px;">
	<p style="overflow-wrap: break-word; margin: 16px 0px; display: block;">
		<span></span>
		<span class="se-drawing-object-wrapper se-image" style="vertical-align: baseline; text-indent: 0px; display: inline-block;">
		</span>
		<span></span>
	</p>
</div>

editor.image.base64.maxSize 결과 예시
